The RPD3000-SA-xx-H-B series of Photodetector are well suited for low-cost, receptacle packages and high-performance in optical networking applications.
The devices feature low capacitance, high linearity, excellent frequency response up to 3000MHz, a wide operating temperature range, and high responsivity. The RPD3000 is also designed to use in a variety of optical network applications including CATV forward/return Path,
PON network, QAM system, EDFA monitors and FTTH applications.

Features
– High responsivity @ 1310/1550nm
– Low capacitance
– 3000MHz frequency response
– High responsivity :
>= 0.80 @ 1310nm
>= 0.85 @ 1550nm

Applications
– CATV forward/return Path
– PON network
– QAM system
– EDFA monitors
– FTTC/FTTH networks
